| Product |
|
|
|
|
| Cellular Router | H8951 | H8952 | H8922S | H8923 |
| Hardware | ||||
| CPU | MIPS 24Kc @580 MHz | MIPS 24Kc 580MHz | MIPS 24Kc @580 MHz | MIPS1004Kc @880 MHz |
| RAM | 128MB | 128MB | 128MB | 256MB |
| FLASH | 16MB | 16MB | 16MB | 32MB |
| Cellular Interface | ||||
| Modem | 1 x LTE CAT4 | 1 × RedCap 5G | 1 or 2 x LTE CAT4 | 1 x 5G NR SA/NSA or 2 x LTE-A or 1 x LTE-A & 1 x 5G NR SA/NSA |
| Number of antennas | 2 | 2 | 2 | 4 |
| Connector | SMA-K | SMA-K | SMA-K | SMA-K |
| SIM | 1 x Mini SIM (2FF) | 2 × Mini SIM (2FF) | 2 x Mini SIM (2FF) | 2 x Mini SIM (2FF) |
| Ethernet Interface | ||||
| Number of ports | 2 x 10/100 Mbps, Ethernet | 2 × 10/100 Mbps, Ethernet | 5 x 10/100 Mbps, Ethernet | 5 x 10/100/1000 Mbps, Gigabit Ethernet |
| Configuration | 2 x LAN or 1 x LAN + 1 x WAN | 2 × LAN or 1 × LAN + 1 × WAN | 5 x LAN or 4 x LAN + 1 x WAN | 4 x LAN + 1 x WAN |
| PoE output | N/A | N/A | N/A | N/A |
| Wireless interface | ||||
| Standards | 802.11b/g/n, AP or station mode | 802.11b/g/n, AP or station mode | 802.11b/g/n, AP or station mode | 802.11b/g/n/ac, AP or station mode |
| Frequency bands | 2.4 GHz | 2.4 GHz | 2.4 GHz | 2.4 GHz & 5GHz |
| Speed | 150Mbps | 150Mbps | 150Mbps | 1167Mbps |
| Security | WEP, WPA, WPA2 | WEP, WPA, WPA2 | WEP, WPA, WPA2 | WEP, WPA, WPA2 |
| Encryption | 64/128 AES, TKIP | 64/128 AES, TKIP | 64/128 AES, TKIP | 64/128 AES, TKIP |
| Antennas | 1 | 1 | 1 | 2 x 2 MIMO |
| (1 would be used in GPS version) | ||||
| Connector | SMA-K | RPSMA-K | RPSMA-K | SMA-K |
| GNSS interface | ||||
| Number of antennas | N/A | N/A | 1 (only for GPS version) | N/A |
| Connector | SMA-K with 50 ohms impedance | SMA-K with 50 ohms impedance | ||
| Dead Reckoning | N/A | N/A | ||
| Seiral interface | ||||
| Type | 1 x RS-232 or 1 x RS-485 serial port | 1 × RS-232 or 1 × RS-485 serial port | 1 x RS-232 + 1 x RS-485 serial port | 1 x RS-232 + 1 x RS-485 serial port |
| Socket form | 1 x 6-pin 3.5 mm female socket | 1 × 6-pin 3.5 mm female socket | 1 x 6-pin 3.5 mm female socket | 1 x 5-pin 3.5 mm female socket |
| Signal definition | RX,TX,GND (RS-232) | RX, TX, GND (RS-232) | RX,TX,GND (RS-232) | RX,TX,GND (RS-232) |
| A+,B-,GND (RS-485) | A+,B-,GND (RS-485) | A+,B-,GND (RS-485) | A+,B-,GND (RS-485) | |
| Baudrate | RS-232 (300-115200bps) | RS-232 (300-115200bps) | RS-232 (300-115200bps) | RS-232 (300-115200bps) |
| RS-485 (300-115200bps) | RS-485 (300-115200bps) | RS-485 (300-115200bps) | RS-485 (300-115200bps) | |
| Software | ||||
| Auto fail-over | Between: | Between: | Between: | Between: |
| Cellular and WAN | Cellular and WAN | 2 Cellulars | 2 Cellulars | |
| Cellular and Wi-Fi (station mode) | Cellular and Wi-Fi (station mode) | Cellular and WAN | Cellular and WAN | |
| WAN and Wi-Fi (station mode) | WAN and Wi-Fi (station mode) | Cellular and Wi-Fi (station mode) | Cellular and Wi-Fi (station mode) | |
| WAN and Wi-Fi (station mode) | WAN and Wi-Fi (station mode) | |||
| Network protocols | PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc. | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH2, DDNS, etc. | PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc. | PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc. |
| Network | APN, VPDN, VLAN, QoS | APN, VPDN, VLAN, QoS | APN, VPDN, VLAN, QoS | APN, VPDN, VLAN, QoS |
| Routing | Static Routing, Policy routing, RIP, OSPF and BGP, etc | Static Routing, Policy routing, RIP, OSPF and BGP, etc | Static Routing, Policy routing, RIP, OSPF and BGP, etc | Static Routing, Policy routing, RIP, OSPF and BGP, etc |
| Firewall | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List |
| VPN | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard |
| Ipsec Encryption | DES, 3DES, AES128, AES192, AES256 | DES, 3DES, AES128, AES192, AES256 | DES, 3DES, AES128, AES192, AES256 | DES, 3DES, AES128, AES192, AES256 |
| OpenVPN Encryption | BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, | BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, | BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, | BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, |
| AES-192-CBC, AES-256-CBC, SEED-CBC |
AES-128-CBC, AES-192-CBC, AES-256-CBC, SEED-CBC |
AES-192-CBC, AES-256-CBC, SEED-CBC | AES-192-CBC, AES-256-CBC, SEED-CBC | |
| Remote Management | HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Wedora Cloud Platform, SDLAN | HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Cloud Platform | HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Wedora Cloud Platform, SDLAN | HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Wedora Cloud Platform, SDLAN |
| Serial ports function | Transparent, Modbus RTU, etc | Transparent, Modbus RTU, etc | Transparent, Modbus RTU, etc | Transparent, Modbus RTU, etc |
| Power Supply and Consumption | ||||
| Power Connector | DC socket | DC socket | DC socket | DC socket |
| Voltage input | +5V~+36V DC | +5V~+36V DC | +5V~+36V DC | +9V~+36V DC |
| Power consumption | Idle: 100mA@12V DC | Idle: 100mA@12V DC | Idle: 200mA@12V DC | Idle: 350mA@12V DC |
| Data transceiving: 350mA@12V DC | Data transceiving: 350mA@12V DC | Data transceiving:550mA@12V DC | Data transceiving:900mA@12V DC | |
| Others | ||||
| Reset button | Yes | Yes | Yes | Yes |
| LED indicators | 4 x indicators for WiFi, RF, NET, SYS | 4 indicators for WiFi, RF, NET, SYS | 10 x indicators for PWR, SYS, WAN, LAN1~LAN4, RF, NET, WLAN | 9 x indicators for PWR, NET1, NET2, DATA, WIFI2.4GHz, WIFI5GHz, Signal |
| Hardware watchdog | Yes | Yes | Yes | Yes |
| Physical Characteristics | ||||
| Ingress protection | IP30 | IP30 | IP30 | IP30 |
| Housing & Weight | Metal, 300g | Metal, 300g | Metal, 540g | Metal, 550g |
| Dimension | 99.7×98.8×23.4(mm) | 99.7×98.8×23.4(mm) | 176×105×25(mm) | 177.8×105.2×28.5(mm) |
| Installations | Desktop, wall mounting | Desktop, wall mounting | Desktop, wall mounting | Desktop, wall mounting |
| Operating temperature | -30 ~ +75℃ | -30 ~ +75℃ | -30 ~ +70℃ | -30 ~ +75 °C |
| Storage temperature | -40 ~ +85 °C | -40 ~ +85 °C | -40 ~ +85 °C | -40 ~ +85 °C |
| Relative humidity | 0~95%(no condensation) | 0~95%(no condensation) | 0~95%(no condensation) | 0~95%(no condensation) |
| EMC | ||||
| ESD | EN61000-4-2, level3 | EN61000-4-2, level3 | EN61000-4-2, level3 | EN61000-4-2, level3 |
| RS | EN 61000-4-3, level3 | EN 61000-4-3, level3 | EN 61000-4-3, level3 | EN 61000-4-3, level3 |
| EFT | EN 61000-4-4, level3 | EN 61000-4-4, level3 | EN 61000-4-4, level3 | EN 61000-4-4, level3 |
| CS | EN 61000-4-6, level3 | EN 61000-4-6, level3 | EN 61000-4-6, level3 | EN 61000-4-6, level3 |
| Certifications | CE, FCC, AT&T, Verizon, T-mobile | CE, RoHS,FCC, IC, PTCRB,RCM, Anatel,GCF,CCC | CE, FCC* | CE*, FCC* |
| (*In progress) | ||||
