| Product |
|
|
|
|
| Industrial | X1 | Z1 | Z2 | Z4 |
| Cellular Gateway | ||||
| Hardware | ||||
| CPU | ARM Cortex-A7 @900MHz | Quad-core ARM Cortex A7 @717MHz | Quad-core ARM Cortex A7 @717MHz | Quad ARM Cortex-A55 2.0GHz |
| RAM | 512MB | 512MB | 512MB | |
| FLASH | 8GB eMMC | 32MB+8GB eMMC | 32MB+8GB eMMC | |
| Cellular Interface | ||||
| Modem | 1 x LTE CAT1/CAT4 | 1 x 5G NR SA/NSA | 1 x 5G NR SA/NSA | 1 × LTE Cat4 or 1/2 × 5G NR SA/NSA |
| Number of Antennas | 2 | 4 | 4 | 2 (LTE version) or 4/8 (NR version) |
| Connector | SMA-K | SMA-K | SMA-K | SMA-K |
| SIM | 2 x Mini SIM (2FF) | 2 x Mini SIM (2FF) | 2 x Mini SIM (2FF) | 2 |
| Wireless Interface | ||||
| Standards | 802.11b/g/n, AP or station modes | 802.11b/g/n/ac, AP or station modes | 802.11b/g/n, AP or station modes | 802.11b/g/n/ac/ax, AP or station modes |
| Frequency Bands | 2.4 GHz | 2.4 GHz & 5GHz | 2.4 GHz | 2.4 GHz & 5 GHz |
| Speed | 150Mbps | 1300Mbps | 150Mbps | 583Mbps |
| Security | WEP, WPA, WPA2 | WEP, WPA, WPA2 | WEP, WPA, WPA2 | WEP, WPA, WPA2 |
| Encryption | 64/128 AES, TKIP | 64/128 AES, TKIP | 64/128 AES, TKIP | 64/128 AES, TKIP |
| Antennas | 1 | 4 | 1 | 2 |
| Connector | SMA-K | SMA-K | SMA-K | SMA-K |
| GNSS Interface | ||||
| Number of Antennas | N/A | 1 (only for GPS version) | 1 (only for GPS version，Share with WiFi) | 1 |
| Connector | SMA-K with 50 ohms impedance | SMA-K with 50 ohms impedance | SMA-K | |
| Dead Reckoning | Optional | N/A | N/A | |
| Peripheral Interface | ||||
| Ethernet | 1 × LAN 10/100Mbps + 1 × WAN/LAN 10/100Mbps, Ethernet | 3 × LAN 10/100/1000 Mbps + 1 × WAN/LAN 10/100/1000 Mbps, Gigabit Ethernet | 1 × LAN 10/100/1000 Mbps + 1 × WAN/LAN 10/100/1000 Mbps, Gigabit Ethernet | 4 x RJ45 10/100/1000Mbps adaptive (1 of which supports WAN, LAN switching) |
| Serial Type | 1 x RS-232 + 1 x RS-485 serial port | 1 x RS-232 + 1 x RS-485 serial port | 1 x RS-232 + 1 x RS-485 serial port | 1 × RS-232/RS-232 + 1 × RS-485 serial port |
| Socket Form | 1 x 7-pin 3.5 mm female socket | 1 x 7-pin 3.5 mm female socket | 1 x 7-pin 3.5 mm female socket | 2 pin socket |
| Signal Definition | RX,TX,GND (RS-232) | RX,TX,GND (RS-232) | RX,TX,GND (RS-232) | |
| A+,B-,GND (RS-485) | A+,B-,GND (RS-485) | A+,B-,GND (RS-485) | ||
| Baudrate | RS-232 (300-115200bps) | RS-232 (300-115200bps) | RS-232 (300-115200bps) | RS-232 (300-115200bps) |
| RS-485 (300-115200bps) | RS-485 (300-115200bps) | RS-485 (300-115200bps) | RS-485 (300-115200bps) | |
| SD card | TF card slot | Built-in TF card slot | TF card slot | TF Card |
| USB | N/A | USB2.0 | 1 x USB2.0 | |
| Software | ||||
| Auto Fail-over | Between: | Between: | Between: | Between: |
| Cellular and WAN | Cellular and WAN | Cellular and WAN | 2 Cellulars, Cellular and WAN | |
| Cellular and Wi-Fi (station mode) | Cellular and Wi-Fi (station mode) | Cellular and Wi-Fi (station mode) | Cellular and Wi-Fi (station mode) | |
| WAN and Wi-Fi (station mode) | WAN and Wi-Fi (station mode) | WAN and Wi-Fi (station mode) | WAN and Wi-Fi (station mode) | |
| Network Protocols | PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc. | PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc. | PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT,HTTP,HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc. | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, SSH, DDNS, etc. |
| Routing | Static Routing, Policy routing, RIP, OSPF and BGP, etc. | Static Routing, Policy routing, RIP, OSPF and BGP, etc. | Static Routing, Policy routing, RIP, OSPF and BGP, etc. | Static Routing, Policy routing, RIP, OSPF and BGP, etc |
| Firewall | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List | NAT, PAT, DMZ, Port Forword, IP/Domain/MAC Filter, Access Control List |
| VPN | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard |
| Remote Management | HTTP, Telnet, SSH, Hongdian Wedora Cloud Platform | HTTP, Telnet, SSH, SMS | HTTP, Telnet, SSH, SMS | HTTP, Telnet, SSH, SMS |
| SNMP V1/V2/V3, SNMP TRAP | SNMP V1/V2/V3, SNMP TRAP | SNMP V1/V2/V3, SNMP TRAP | ||
| Hongdian Wedora Cloud Platform | Hongdian Wedora Cloud Platform | Hongdian Wedora Cloud Platform | ||
| Serial Ports Function | Transparent, Modbus RTU, etc. | Transparent, Modbus RTU, etc. | Transparent, Modbus RTU, etc. | Transparent, Modbus RTU, etc |
| Power Supply and Consumption | ||||
| Connector | 2 pin socket | 2 pin socket | 2 pin socket | 2 pin socket |
| Voltage Input | +5V~+36V DC | +9V~+24V DC | +9V~+36V DC | +9V~+48V DC |
| Power Consumption | Idle:180mA@12V DC | Idle: 450mA@12V DC | Idle: 350mA@12V DC | Idle: 400mA@12V DC |
| Data transceiving: 300mA@12V DC | Data transceiving: 2.2A@12V DC | Data transceiving:1.3A@12V DC | Data transceiving: 1.5A@12V DC | |
| Others | ||||
| Reset Button | Yes | Yes | Yes | Yes |
| LED Indicators | 4 x indicators for SIG, SYS, NET, WiFi | 4 x indicators for WiFi, SIG, NET, SYS | 4 x indicators for WiFi, SIG, NET, SYS | 6 indicators for PWR, WLAN, NET1, SIG1, DATA/NET2, LORA/SIG2 |
| 4 x indicators for PLA1, PLA2, TX1, TX2 | ||||
| Hardware Watchdog | Yes | Yes | Yes | Yes |
| Physical Characteristics | ||||
| Ingress Protection | IP43 | IP66 | IP66 | IP30 |
| Housing & Weight | Metal,285g | Metal, 1860g | Metal, 290g | Metal, 1060g |
| Dimension | 127×83×24(mm) | 216×216×51.5(mm) | 137×83×24(mm) | 170 × 136.2× 51mm |
| Installations | Desktop, wall mounting and DIN rail mounting | Desktop, wall mounting and surface mounting | Desktop, wall mounting and DIN rail mounting | Desktop, wall mounting and DIN rail mounting |
| Operating Temperature | -30 ~ +70 °C | -30 ~ +70℃ | -30 ~ +70℃ | -35 ~ +75℃ |
| Storage Temperature | -40 ~ +85 °C | -40 ~ +85 °C | -40 ~ +85 °C | -40 ~ +85℃ |
| Relative Humidity | 5 ~ 95% | 5 ~ 95% | 5 ~ 95% | 95% |
| EMC | ||||
| ESD | EN61000-4-2, level3 | EN61000-4-2, level3 | EN61000-4-2, level3 | EN61000-4-2, level3 |
| RS | EN 61000-4-3, level3 | EN 61000-4-3, level3 | EN 61000-4-3, level3 | EN 61000-4-3, level3 |
| EFT | EN 61000-4-4, level3 | EN 61000-4-4, level3 | EN 61000-4-4, level3 | EN 61000-4-4, level3 |
| CS | EN 61000-4-6, level3 | EN 61000-4-6, level3 | EN 61000-4-6, level3 | EN 61000-4-6, level3 |
